System 15: Fresno
Details for System 15
About the System:

Planning a trip to Fresno or down to Central California? C.A.R.L.A. 15 will keep you company on I-5 and I-99 through Fresno, Kings and Kern Counties.

System 15: Fresno

Link PL:162.2
Local PL:114.8
Site Name:Joaquin Ridge
City:Coalinga, CA
Controller:SCOM 7330
System Config:Permanent Dual PL Link/Local System

System Equipment Photo
Click the thumbnail below for a larger view

Dual PL & Courtesy Tones
This particular repeater in the C.A.R.L.A. System has a Dual PL. You can use the Link PL to hold a conversation with someone elsewhere on the network, or the Local PL to converse with someone who is on the same repeater as you are.

You can read more about the Dual PL system and the Courtesy Tones that are used on the system.

Coverage for System 15
Located on Joaquin Ridge near Coalinga with coverage in the Southern Central Valley along the I-5 & Hwy 99 corridors from Turlock & Patterson to Fresno, Bakersfield and Grapevine. This machine can also be heard in a few parts of Yosemite.

See this system on our Interactive Coverage Map

Disclaimer: Coverage maps are provided for informational purposes only.
C.A.R.L.A. would like to acknowledge and thank Radio Mobile for the use of their program.

Technical Data for System 15
For the curious amongst us, here are further details about the equipment that makes up this C.A.R.L.A. System. For example, you can see what kind of transceiver we're using for a particular repeater, or what kind of link antenna, etc. If there are other repeaters or connections present, you can click on their name for further information.
In Service Degraded OOS

In ServiceSystem 15
Equipment:Motorola MSF5000 CXB
Transmit Power:40w
Antenna:Super Station Master Omni with 8 dB of gain
Click Here to see any current alerts for this system
In ServiceMain Link
Type:RF Link (connects to the Vaca Hub)
Equipment:Motorola CDM
Transmit Power:20w
Antenna:Antennex Y4066 Yagi with 10.2 dB of gain
